Model：10T 560215 S1
Benchmarking model: ContiTech 940 MB P30
Interchangeability model:Vibracoustic V1DK21KY4; V1DK21KX4; Firestone W01-M58-8585
Product features: designed for China's road conditions and use conditions, the piston is strengthened, and the internal design has anti-collision buffer block, which is more safe and durable.
- Product details
| Bearing capacity at 7bar internal pressure | 30kN |
| Maximum allowable internal pressure at standard height | 8.5bar |
| Burst pressure | >21bar |
| Maximum outer diameter | 300mm |
| Minimum installation space required | 330mm |
| Maximum allowable height | 560mm |
| Stop height | 215mm |
| proper temperature | -40℃~60℃ |
| Weight | |
| Piston material | Engineering plastics |
